BRC Steel Matting Fence Mesh is a popular welded wire fencing system widely used across Southeast Asia. It combines high durability, attractive design, and easy installation. This makes it perfect for securing various locations like airports, gardens, highways, and commercial buildings.
This roll top fence / BRC is very popular in Australia, Southeast Asia,Euro Market,etc. It is suitable where safety is a consideration, such as schools, sports, parks and playgrounds, and company premises.
Features
Bottom “Rolled” Edges
BRC fencing is also called Euro fence or Anchor Link fence. Its unique top and bottom “rolled” edges are not only decorative but also give each panel strong rigidity. These rolled edges act as horizontal supports between fence posts.
Ideal Security Fencing
The uniform spacing of BRC fencing improves its appearance and provides excellent visibility, even at night. This makes it an ideal choice for security fencing.
Panels can be replaced easily, and the spacing between wires allows precise cutting for custom sizes.
Simple and Easy Installation
Installation of BRC fence is simple and straightforward. Each package includes panels, posts, post caps, U-clips, bolts, and nuts. Surface treatments include hot-dip galvanizing (MS 740:1981 equivalent to BS 729:1971) or powder coating in various colors. Steel posts come pre-drilled, ready for quick assembly on-site. For fence heights above 2.4 meters, a “Multi-lift erection system” is recommended, allowing multiple panels to stack securely.
What is BRC Steel Matting Fence Mesh?
BRC Steel Matting Fence Mesh is a welded wire fence popular in Southeast Asia. It offers high strength, attractive looks, and easy installation. Each panel has rolled edges at the top and bottom for improved safety.
Specifications of BRC Steel Matting Fence Mesh
| Item | Mesh Spacing (Vertical x Horizontal) mm | Wire Diameter (mm) | Panel Size (Height x Width) mm | Material | Features |
|---|---|---|---|---|---|
| Type 1 | 50 x 150 | 4.0, 4.5, 5.0, 6.0 | 900 x 2400 1200 x 2400 1500 x 2400 1800 x 2400 2100 x 2400 2400 x 2400 |
Low carbon steel Q195/Q235 | Welded wire, rolled top and bottom edges |
| Type 2 | 50 x 100 | 4.0, 4.5, 5.0, 6.0 | 900 x 2400 1200 x 2400 1500 x 2400 1800 x 2400 2100 x 2400 2400 x 2400 |
Low carbon steel Q195/Q235 | Welded wire, rolled top and bottom edges |
| Type 3 | 50 x 200 | 4.0, 4.5, 5.0, 6.0 | 900 x 2400 1200 x 2400 1500 x 2400 1800 x 2400 2100 x 2400 2400 x 2400 |
Low carbon steel Q195/Q235 | Welded wire, rolled top and bottom edges |
| Type 4 | 75 x 150 | 4.0, 4.5, 5.0, 6.0 | 900 x 2400 1200 x 2400 1500 x 2400 1800 x 2400 2100 x 2400 2400 x 2400 |
Low carbon steel Q195/Q235 | Welded wire, rolled top and bottom edges |
| Type 5 | 75 x 200 | 4.0, 4.5, 5.0, 6.0 | 900 x 2400 1200 x 2400 1500 x 2400 1800 x 2400 2100 x 2400 2400 x 2400 |
Low carbon steel Q195/Q235 | Welded wire, rolled top and bottom edges |
Key Features:
- Material: High-quality low carbon steel (Q195/Q235).
- Wire Diameter: Heavy-duty wire (4.0mm to 6.0mm) ensures rigidity and strength.
- Panel Sizes: Customizable from 900mm to 2400mm in height; standard width is 2400mm.
- Design: Rolled top and bottom edges for safety and enhanced rigidity.
Applications of BRC Steel Matting Fence Mesh
BRC Steel Matting Fence Mesh has wide usage:
- Airports, ports, and harbors
- City construction sites
- Gardens, parks, and zoos
- Pools and lakes
- Roads and highways
- Hotels, restaurants, supermarkets
- Factories, buildings, and mining areas
Benefits of BRC Steel Matting Fence Mesh
- Attractive Design: Rounded edges and triangle folds enhance visual appeal.
- High Strength: Welded steel wires ensure durability and strength.
- Easy Installation: Simple design makes setup and removal fast.
- Long Lifespan: Protective coatings guarantee years of use.
- Minimal Maintenance: Requires low maintenance, saving time and cost.
Frequently Asked Questions (FAQ)
Q: What makes BRC Steel Matting Fence Mesh strong?
A: High tensile steel wires welded together ensure strength and rigidity.
Q: Is the BRC Steel Matting Fence Mesh safe?
A: Yes, rolled top and bottom edges eliminate sharp points, ensuring safety.
Q: Can I choose different colors?
A: Yes, various colors are available to match your preferences.
Q: What details should I provide to receive an accurate quotation?
A: Please specify material type, mesh size, wire diameter, panel dimensions, quantity, and finishing requirements.
Q: Do you provide samples?
A: Yes, we can provide samples of half A4 size along with our catalogue. Shipping charges will initially be your responsibility but will be refunded upon order placement.
Q: How long is the delivery time?
A: For stock materials, delivery is typically within 7 days. For custom or non-stock items, delivery time will be confirmed by our production department.
Q: How is the fencing shipped?
A: Usually by sea freight, ensuring safe and efficient transportation.
Q: What payment methods do you accept?
A: We accept payment via T/T, L/C, D/P, and Western Union.
Packaging of BRC Fencing
Proper packaging is crucial during transportation to prevent damage to products. We ensure our BRC fencing products are packaged securely using bubble film and foam board. Additionally, iron pallets may be included for enhanced protection during transit. Customized packaging solutions are also available according to specific customer requirements.
Conclusion:
Choosing BRC Steel Matting Fence Mesh gives you a strong, secure, and attractive fencing option. Its easy installation, low maintenance, and durability offer excellent value. Whether for protection or decoration, BRC Steel Matting Fence Mesh meets all your fencing needs effectively.
